MV Connectors 804PB-58

Application

Surge arrester designed to protect 12, 24, 36 and 42 kV class components, including transformers, equipment, cable and accessories from high voltage surges resulting from lightning or switching. It has been designed to be used with the 784TB separable tee connectors.

Technical characteristics

• This surge arrester is a metal oxide varistor surge arrester in a elbow configuration.
• Each arrester is tested for AC withstand, partial discharge and critical voltage prior to leaving the factory.

Benefits

• Safe & reliable: with their slip-on technology, EUROMOLD^®’s separable connectors are safe to install. Each separable connector is made with high quality components in Europe and individually tested before leaving the plant, ensuring a reliable connection and high-quality product.
• Easy to install: make your job easier with slip-on separable connectors. They can be removed easily, when deenergized, without specific tools, and safely, thanks to high quality EPDM rubber inner and outer jackets, ensuring a long-lasting protection. The compact design is adapted to limited installation spaces.
• Compact design: the compact design of separable connectors uses less raw material and limits sub packaging. It also reduces production and storage costs.
• All-in-one solution: EUROMOLD^®’s separable connectors fit every project with their different shapes available for a wide range of cross sections for all interfaces from A to F.
