MV Connectors 676LRA

Application

Separable tee connector designed to connect polymeric insulated cable to equipment (transformers, switchgear, motors...). Also connects cable to cable, using the appropriate mating part.

Technical characteristics

• A thick conductive EPDM jacket provides a total safe to touch screen.
• Each separable connector is tested for AC withstand and partial discharge prior to leaving the factory.

Benefits

• Safe & reliable: with their slip-on technology, EUROMOLD^®’s separable connectors are safe to install. Each separable connector is made with high quality components in Europe and individually tested before leaving the plant, ensuring a reliable connection and high-quality product.
• Easy to install: make your job easier with slip-on separable connectors. They can be removed easily, when deenergized, without specific tools, and safely, thanks to high quality EPDM rubber inner and outer jackets, ensuring a long-lasting protection. The compact design is adapted to limited installation spaces.
• Compact design: the compact design of separable connectors uses less raw material and limits sub packaging. It also reduces production and storage costs.
• All-in-one solution: EUROMOLD^®’s separable connectors fit every project with their different shapes available for a wide range of cross sections for all interfaces from A to F.
