MV Transition Joints JTM3 K

Application

JTM3 K heat-shrink transition joints are designed to connect three core plastic insulated cables with Cu wire/tape screen armored and three core paper insulated armored PILC (1 Lead) cables.

Technical characteristics

JTM3 K is the NEW high performance, compact and easy to install joint.
A single body with all the electrical functions integrated!
The Nexans “TRIPLE GT125” is an integrated stress control field, insulating and conductive tube, which can withstand high voltage applications up to 24kV and up to 400 mm².
For 36kV a double dual layer tube is used.
A double layer pad with conductive rubber inside and HK orange mastic outside ensure a Faraday cage and smooth the effect of the electrical field in the connector area.
Screen connection and armor continuity material whether SWA, STA, DSTA are included in the kit.
MC types are supplied with GPH^® mechanical connectors.
The outer sheath is restored with heavy/medium wall adhesive lined tubing.
